Toro 41106 - Table of Contents

2
All Rights Reserved
Printed in the USA
 2003 by The Toro Company
8111 Lyndale Avenue South
Bloomington, MN 55420-1196
CALIFORNIA
Proposition 65 Warning
The engine exhaust from this product contains
chemicals known to the State of California to cause
cancer, birth defects, or other reproductive harm.
Warning
Important The engine in this product is not equipped
with a spark arrester muffler. It is a violation of California
Public Resource Code Section 4442 to use or operate this
engine on any forest-covered, brush-covered, or
grass-covered land as defined in CPRC 4126. Other states
or federal areas may have similar laws.
This spark ignition system complies with Canadian
ICES-002.
Ce système d’allumage par étincelle de véhicule est
conforme à la norme NMB-002 du Canada.
Contents
Page
Introduction 3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Safety 3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Safe Operating Practices 3. . . . . . . . . . . . . . . . . . . .
Chemical Safety 4. . . . . . . . . . . . . . . . . . . . . . . . . .
Before Operating 4. . . . . . . . . . . . . . . . . . . . . . . . .
While Operating 5. . . . . . . . . . . . . . . . . . . . . . . . . .
Maintenance 6. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Sound Pressure 7. . . . . . . . . . . . . . . . . . . . . . . . . . .
Vibration 7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Safety and Instruction Decals 7. . . . . . . . . . . . . . . .
Specifications 10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Optional Equipment 10. . . . . . . . . . . . . . . . . . . . . . .
Setup 11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Loose Parts 11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installing the Anti-siphon Fill Receptacle 12. . . . . .
Installing the Spray Pro Monitor 12. . . . . . . . . . . . .
Before Operating 13. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Checking the Engine Oil 13. . . . . . . . . . . . . . . . . . .
Checking the Tire Pressure 13. . . . . . . . . . . . . . . . . .
Adding Fuel 13. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Checking the Air Intake Screen 14. . . . . . . . . . . . . .
Checking the Brake Fluid 14. . . . . . . . . . . . . . . . . . .
Checking the Transaxle/Hydraulic Fluid 14. . . . . . .
Filling the Fresh Water Tank 15. . . . . . . . . . . . . . . .
Page
Operation 15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Think Safety First 15. . . . . . . . . . . . . . . . . . . . . . . . .
Vehicle Controls 15. . . . . . . . . . . . . . . . . . . . . . . . . .
Pre-Starting Checks 17. . . . . . . . . . . . . . . . . . . . . . .
Starting the Engine 17. . . . . . . . . . . . . . . . . . . . . . . .
Driving the Sprayer 17. . . . . . . . . . . . . . . . . . . . . . .
Stopping the Engine 18. . . . . . . . . . . . . . . . . . . . . . .
New Sprayer Break-In 18. . . . . . . . . . . . . . . . . . . . .
Transporting the Sprayer 18. . . . . . . . . . . . . . . . . . .
Towing the Sprayer 18. . . . . . . . . . . . . . . . . . . . . . .
Sprayer Controls and Components 18. . . . . . . . . . . .
Spray Prot Monitor 21. . . . . . . . . . . . . . . . . . . . . . . .
Calibrating the Spray Pro Monitor 22. . . . . . . . . . . .
Adjusting the Boom Bypass Valves 23. . . . . . . . . . .
Operating the Sprayer 24. . . . . . . . . . . . . . . . . . . . . .
Maintenance 26. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Recommended Maintenance Schedule 26. . . . . . . . .
Daily Maintenance Checklist 27. . . . . . . . . . . . . . . .
Jacking the Sprayer 28. . . . . . . . . . . . . . . . . . . . . . .
Inspecting the Wheels/Tires 28. . . . . . . . . . . . . . . . .
Servicing the Air Cleaner 28. . . . . . . . . . . . . . . . . . .
Servicing the Engine Oil 30. . . . . . . . . . . . . . . . . . .
Greasing the Sprayer 31. . . . . . . . . . . . . . . . . . . . . .
Replacing the Fuel Filter 32. . . . . . . . . . . . . . . . . . .
Changing Transaxle/Hydraulic Fluid 33. . . . . . . . . .
Replacing the Hydraulic Filter 33. . . . . . . . . . . . . . .
Changing the Pump Drive Gearbox Fluid 34. . . . . .
Inspecting the Brakes 34. . . . . . . . . . . . . . . . . . . . . .
Adjusting the Parking Brake 34. . . . . . . . . . . . . . . .
Adjusting the Front Wheel Toe-In 34. . . . . . . . . . . .
Servicing the Drive Belt 35. . . . . . . . . . . . . . . . . . . .
Adjusting the Steering Pump Belt 36. . . . . . . . . . . .
Changing the Spark Plugs 36. . . . . . . . . . . . . . . . . .
Replacing the Fuses 37. . . . . . . . . . . . . . . . . . . . . . .
Servicing the Battery 37. . . . . . . . . . . . . . . . . . . . . .
Cleaning the Suction Strainer 39. . . . . . . . . . . . . . . .
Cleaning the Flowmeter 39. . . . . . . . . . . . . . . . . . . .
Storage 40. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Troubleshooting 41. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Troubleshooting the Engine and Vehicle 41. . . . . . .
Troubleshooting the Spray System 44. . . . . . . . . . . .
Troubleshooting the Spray Pro Monitor 44. . . . . . . .
The Toro General Commercial Products Warranty 48. .
