Lubrication
LubricatethemachinewhenshownontheCheck
ServiceReferenceAiddecal(Figure32).Grease
morefrequentlywhenoperatingconditionsare
extremelydustyorsandy.
GreaseType:General-purposegrease.
GreasingtheMachine
1.DisengagethePTO,movethemotion-control
leverstotheNEUTRAL-LOCKposition,andsetthe
parkingbrake.
2.Shutofftheengine,removethekey,andwait
forallmovingpartstostopbeforeleavingthe
operatingposition.
3.Cleanthegreasettingswitharag.Makesure
toscrapeanypaintoffthefrontofthetting(s).
4.Connectagreaseguntothetting.Pump
greaseintothettingsuntilgreasebeginsto
oozeoutofthebearings.
5.Wipeupanyexcessgrease.
GreasingtheFrontCaster
Pivots
Lubricatethefrontcasterpivotsonceayear.
1.Removethedustcapandadjustthecaster
pivots.Keepthedustcapoffuntilgreasing
isdone.RefertoAdjustingtheCaster-Pivot
Bearing(page45).
2.Removethehexplug.Threadagreasetting
intothehole.
3.Pumpgreaseintothettinguntilitoozesout
aroundthetopbearing.
4.Removethegreasettinginthehole.Installthe
hexplugandcap.
AddingGrease
LubricatethegreasettingsasshownontheCheck
ServiceReferenceAiddecal(Figure32).
g005930
Figure32
AddingLightOilorSpray
Lubrication
ServiceInterval:Every150hours
Lubricatethemachineinthefollowingareaswith
spraytypelubricantorlightoil.
•Seatswitchactuator.
•Brakehandlepivot.
•Brakerodbushings.
•Motioncontrolbronzebushings.
GreasingtheMowerDeck
andBeltIdlers
ServiceInterval:Every25hours—Greasethemower
deckandspindles.
Every25hours—Greasethepumpbeltidler
arm.
Every25hours—Greasethedrivebeltidlerarm.
GreasewithNo.2lithiumormolybdenumgrease.
Important:Makesurecuttingunitspindlesare
fullofgreaseweekly.
1.DisengagethePTO,movethemotion-control
leverstotheNEUTRAL-LOCKposition,andsetthe
parkingbrake.
