g000968
Figure65
1.Alternator4.Topbolt
2.Alternatorbelt5.Bottombolt
3.Deection,7to9mm(1/4
to11/32inch)with10kgf
(22.1lbofforce)
ControlsSystem
Maintenance
AdjustingtheControl
HandleNeutralPosition
Ifthemotion-controlleversdonotalign,ormove
easilyintotheconsolenotch,adjustmentisrequired.
Adjusteachlever,springandrodseparately.
Note:Themotion-controlleversmustbeinstalled
correctly.SeeInstallingtheMotionControlLeversin
thesetupinstructions.
1.DisengagethePTO,movethemotion-control
leverstotheNEUTRAL-LOCKposition,andsetthe
parkingbrake.
2.Shutofftheengine,removethekey,andwait
forallmovingpartstostopbeforeleavingthe
operatingposition.
3.Unlatchtheseatandtilttheseatforward.
4.Beginwitheithertheleftorrightmotion-control
lever.
5.Movethelevertotheneutralpositionbutnot
locked(Figure66).
6.Pulltheleverbackuntiltheclevispin(onarm
belowpivotshaft)contactstheendoftheslot
(justbeginningtoputpressureonthespring)
(Figure66).
7.Checkwherethecontrolleverisrelativeto
notchinconsole(Figure66).Itshouldbe
centeredallowinglevertopivotoutwardtothe
NEUTRAL-LOCKposition.
g001046
Figure66
1.NEUTRAL-LOCKposition3.NEUTRALposition
2.Controllever
8.Ifadjustmentisneeded,loosenthenutandjam
nutagainsttheyoke(Figure67).
52
