Toro 74279TE - Replacing the PTO Drive Belt

g005911
Figure60
1.Ratchetwithshort
extensionorbreaker
bar
3.Spring-loadedidlerpulley
2.16.5cm(6-1/2inches)
betweenthespringhooks
4.FixedIdlerpulley
12.Whileholdingthebeltintension,tightenthe2
boltsthatsecurethexedidlerarm.
13.Removetheratchetorbreakerbarfromthe
squareholeinthexedidlerarm.
14.Installthebeltcoverswiththetabsintheslots.
Installthescrewsandclosethelatches(Figure
61).
g012506
Figure61
1.Beltcover3.Bolt
2.Latch4.Installtabintotheslot
15.Installthesheetmetalguard.RefertoRemoving
theSheet-MetalGuard(page32).
16.Tightentheboltforthemower-deckcurtain.
RefertoReleasingtheMower-DeckCurtain
(page32).
17.Checkthetensiononthedrivebelts.
ReplacingthePTODrive
Belt
ServiceInterval:Every50hours—CheckthePTO
drivebelt.
Important:Thefastenersforthefrontengine
panelaredesignedtoremainonthemachineafter
coverremoval.Loosenallofthefastenersafew
turnssothatthepanelisloosebutstillattached,
thengobackandloosenthemuntilthepanel
comesfree.Thispreventsyoufromaccidentally
strippingtheboltsfreeoftheretainers.
Squealingwhenthebeltisrotating,bladesslipping
whencuttinggrass,frayedbeltedges,burnmarks,
andcracksaresignsofawornPTObelt.Replacethe
mowerbeltifanyoftheseconditionsareevident.
1.DisengagethePTO,movethemotion-control
leverstotheNEUTRAL-LOCKposition,andsetthe
parkingbrake.
2.Shutofftheengine,removethekey,andwait
forallmovingpartstostopbeforeleavingthe
operatingposition.
3.Tilttheseatforward,loosenthebolts,and
removethefrontenginepanel(Figure62).
g012347
Figure62
1.Bolt2.Frontenginepanel
4.Removethespringfromtheidlerarm(Figure
63).
5.Removetheclutchstopbracket.
50
