Problem
PossibleCauseCorrectiveAction
1.Thecuttingblade(s)is/arenotsharp.1.Sharpentheblade(s).
2.Thecuttingblade(s)is/arebent.2.Installnewcuttingblade(s).
3.Themowerdeckisnotlevel.
3.Levelthemowerdeckfromside-to-side
andfront-to-rear.
4.Theundersideofmowerisdirty.4.Cleantheundersideofthemower.
5.Thetirepressureisnotcorrect.5.Adjustthetirepressure.
Thecuttingheightisuneven.
6.Thebladespindleisbent.
6.ContactanAuthorizedServiceDealer.
1.ThePTOdrivebeltisworn,looseor
broken.
1.Checkthebelttension.
2.ThePTOdrivebeltisoffpulley.
2.Installthedrivebeltandcheck
adjustingshaftsandbeltguidesfor
correctposition.
3.Themowerdeckbeltisworn,loose
orbroken.
3.Installanewmowerdeckbelt.
4.Themowerdeckbeltcameoffapulley.
4.Installmowerdeckbeltandcheckthe
idlerpulley,idlerarmandspringforthe
correctpositionandfunction.
5.Thepumpdrivebeltisworn,looseor
broken.
5.Installanewmowerdeckbelt.
6.Thepumpdrivebeltcameoffapulley.
6.Installmowerdeckbeltandcheckthe
idlerpulley,idlerarmandspringforthe
correctpositionandfunction.
Thecuttingbladesdonotrotate.
7.Theidlerspringisbrokenormissing.7.Replacethespring.
