Toro 78280 - Installation; Loose Parts

3
Installation
Loose Parts
Note: Use the chart below to identify parts used for assembly.
DESCRIPTION QTY. USE
Gage wheel
Shoulder bolt
Locknut 3/8–24 (with patch on threads)
2
2
2
Install gage wheels
Rear link
Washer 1/2” (13 mm)
Cotter pin 1” (26 mm)
1
2
2
Install rear link
Adjustable links
Washer 3/8” (10 mm)
Cotter pin 1” (26 mm)
2
2
2
Install front mount to mower
Grass deflector
Spring
Bolt 3/8– 24 x 3-1/2” (89 mm)
Locknut 3/8–24
1
2
2
2
Install grass deflector
Up stop 1 Install mower up stop
Hairpin cotter 3-3/8” (85 mm)
Washer 3/4” (19 mm)
Link pin
Hairpin cotter2-9/16” (65 mm)
Washer 1/2” (13 mm)
2
2
1
3
3
Install mower to tractor
Operator’ s Manual
Warranty card
1
1
Read before operating
