Toro Greenmaster Flex 1820 - Preparing the Traction Unit; Installing the Cutting Unit to the Traction Unit

1
PreparingtheTractionUnit
Optional—CuttingUnitModels
04251,02452,04253,or04254
NoPartsRequired
Procedure
IfyouareinstallingcuttingunitModels04251,02452,
04253,or04254onthistractionunit,completethe
followingsteps:
1.Positionthecuttingunitonaat,levelsurface.
2.Onbothpitcharms(Figure3),measure2.3mm
(0.09inch)inonthetabsandgrinddownthe
cornerasshowninFigure4.
g034505
Figure3
1.Pitcharms
g034506
Figure4
3.Painttherevealedmetaltopreventcorrosion.
2
InstallingtheCuttingUnit
totheTractionUnit
Partsneededforthisprocedure:
2
Bolt(3/8x3/4inch)
Procedure
Note:Toinstalltheweightrodontoyourmachine,
refertotheinstallationinstructionsinyourcuttingunit
Operator’sManual.
1.Placethemoweronitsdrumsonalevelsurface.
2.Lowerthekickstandandpushinthelockingpin
tolockthekickstandintheSERVICEposition
(Figure5).Allowthemachinetorestonthe
lockedkickstand.
Note:PlacethekickstandintheSERVICE
positionwheneveryouremovethecuttingunit.
Thiskickstandpositionkeepsthemachinefrom
tippingbackwardontothehandle.
g018142
Figure5
1.Kickstand—STORAGE
position
3.Kickstand—SERVICE
position
2.Lockingpin
3.Pushthecuttingunitunderthetractionunitand
tothelefttoengagethetransmissioncoupling
(Figure6).
8
