Groundsmaster 3500Hydraulic System Page 5 − 134
Sidewinder
1. Bushing
2. Scissor link
3. Scissor mount
4. Cap screw
5. Flat washer
6. Lock nut
7. Scissor frame
8. Hydraulic cylinder
9. Spacer
10. Flat washer
11. Cap screw
12. Lock nut
13. Welded pin
14. Flange head screw
15. Lock nut
16. Spacer
17. Hydraulic tube
18. Hydraulic tube
19. 90
o
hydraulic fitting
20. Bulkhead lock nut
21. Straight hydraulic fitting
22. Hydraulic hose
23. 90
o
hydraulic fitting
24. Hydraulic hose
25. Scissor link
26. O–ring
27. O–ring
28. O–ring
29. Retaining ring
30. Lower frame
31. Frame
32. Pinch point decal
Figure 91
14
1
7
1
13
14
18
4
25
5
6
8
19
19
13
11
17
9
1
12
10
10
12
1
9
16
21
22
24
23
15
2
3
15
1
20
11
26
26
31
30
29
28
28
27
27
32
FRONT
RIGHT
