Toro LT3340 - InfoCenter LCD Display Operation; InfoCenter Icon Descriptions

UsingtheInfoCenterLCDDisplay
TheInfoCenterLCDdisplayshowsinformationabout
yourmachine,suchastheoperatingstatus,various
diagnostics,andotherinformationaboutthemachine
(Figure16).Thereisasplashscreenandmain
informationscreenoftheInfoCenter.Youcanswitch
betweenthesplashscreenandmaininformation
screenatanytimebypressinganyoftheInfoCenter
buttonsandthenselectingtheappropriatedirectional
arrow.
g020650
Figure16
1.Indicatorlight3.Middlebutton
2.Rightbutton
4.Leftbutton
•LeftButton,MenuAccess/BackButton—pressthis
buttontoaccesstheInfoCentermenus.Youcan
useittoexitanymenuthatyouarecurrentlyusing.
•MiddleButton—usethisbuttontoscrolldown
menus.
•RightButton—usethisbuttontoopenamenu
wherearightarrowindicatesadditionalcontent.
Note:Thepurposeofeachbuttonmaychange
dependingonwhatisrequiredatthetime.Each
buttonislabeledwithanicondisplayingitscurrent
function.
InfoCenterIconDescriptions
SERVICEDUE
Indicateswhenscheduledservice
shouldbeperformed
Hoursremaininguntilservice
Resettheservicehours.
Thestatusoftheenginespeed
(rpm)—InfoCenterdisplayin
languagesotherthanEnglish
Thestatusoftheenginespeed
(rpm)—InfoCenterdisplayinEnglish
Infoicon
Stationaryregenerationisrequired.
Theair-intakeheaterisactive.
Theoperatormustsitintheseat.
Theparkingbrakeisengaged.
Neutral
Coolanttemperature(°Cor°F)
Temperature(hot)
Notallowed
Starttheengine.
ThePTOison.
Shutofftheengine.
Engine
Keyswitch
Cuttingunitsarelowering
Cuttingunitsareraising
CANbus
InfoCenter
Badorfailed
Center
