• If the sno wthro w er does not mo v e or mo v es
forw ard when it is in P osition R1, remo v e the
tr unnion from the speed selector lev er , tur n the
tr unnion do wnw ard (cloc kwise) on the speed
control rod, then install the tr unnion.
• If the sno wthro w er does not mo v e or mo v es
rearw ard when it is in P osition 1 (forw ard), remo v e
the tr unnion from the speed selector lev er , tur n the
tr unnion upw ard (countercloc kwise) on the speed
control rod, then install the tr unnion.
Note: R efer to Installing the T raction Control
Linkag e .
Note: If the sno wthro w er mo v es when the
traction lev er is in the released position, c hec k the
traction cable (refer to Chec king and Adjusting
the T raction Cable) or tak e the sno wthro w er to an
A uthorized Ser vice Dealer for ser vice .
Operating the Speed Selector
T he speed selector has 6 forw ard and 2 rev erse g ears . T o
c hang e speeds , release the traction lev er and shift the speed
selector lev er to the desired position ( Figure 29 ). T he lev er
loc ks in a notc h at eac h speed selection.
Figure 29
Operating the Auger/Impeller
Drive
1. T o eng ag e the aug er/ impeller dri v e , squeeze the right
hand (aug er/ impeller) lev er to the handg rip ( Figure 30 ).
Figure 30
2. T o stop the aug er and impeller , release the right hand
lev er .
Important: W hen y ou enga ge both the
auger/impeller lev er and the traction lev er , the
traction lev er locks the auger/impeller lev er do wn,
fr eeing y our right hand. T o r elease both lev er s,
simpl y r elease the left hand (traction) lev er .
3. If the aug er and impeller contin ue to rotate when y ou
release the aug er/impeller lev er , do not operate the
sno wthro w er . Chec k the aug er/impeller cable (refer to
Chec king and Adjusting the A ug er/Impeller Cable) and
adjust it if necessar y . Otherwise , tak e the sno wthro w er
to an A uthorized Dealer for ser vice .
If the auger and impeller contin ue to r otate when
y ou r elease the auger/impeller lev er , y ou could
seriousl y injur e y our self or other s.
Do not operate the sno wthr o w er . T ak e it to an
Authoriz ed Ser vice Dealer f or ser vice.
Operating the Quick Stick™
Hold the blue trig g er cap do wn to use the Quic k Stic k to
mo v e the disc harg e c hute and the c hute deflector . R elease
the trig g er cap to loc k the disc harg e c hute and c hute
deflector into position ( Figure 31 ).
Figure 31
Moving the Discharge Chute
Hold the blue trig g er cap do wn and mo v e the Quic k Stic k
to the left to mo v e the disc harg e c hute to the left; mo v e
the Quic k Stic k to the right to mo v e the disc harg e c hute to
the right ( Figure 32 ).
12
