Product Overview
Figure 14
1. Auger/impeller lever 8. Chute deector
2. Speed selector lever 9. Discharge chute
3. Quick Stick™ discharge chute
control
10. Fuel shutoff valve
4. Traction lever
11. Skid (2)
5. Headlight
12. Auger
6. Fuel tank
13. Scraper
7. Engine oil ll tube/dipstick
Figure 15
1. Ignition switch
4. Primer
2. Choke 5. Electric starter
3. Throttle 6. Recoil starter
Operation
Note: Deter mine the left and right sides of the mac hine
from the nor mal operating position.
Freewheeling or Using the
Self-propel Drive
Y ou can operate the sno wthro w er with the self-propel
feature eng ag ed or diseng ag ed (freewheeling).
T o freewheel, slide the wheels inw ard and inser t the axle
pins through the outer axle holes , but not through the wheel
hubs ( Figure 16 ).
Figure 16
T o self-propel, slide the wheels outw ard and inser t the axle
pins through the holes in the wheel hubs and the inner axle
holes ( Figure 17 ).
Figure 17
Filling the Fuel Tank
Gasoline is extr emel y flamma ble and explosi v e. A
fir e or explosion fr om gasoline can bur n y ou and
other s.
• T o pr ev ent a static charge fr om igniting the
gasoline, place the container and/or sno wthr o w er
on the g r ound bef or e filling , not in a v ehicle or
on an object.
• Fill the tank outdoor s when the engine is cold.
W ipe up spills.
• Do not handle gasoline when smoking or ar ound
an open flame or spar ks.
• Stor e gasoline in an appr o v ed fuel container , out
of the r each of childr en.
9
