Toro ProCore 864 - 12 Removing the Storage Stands

4.PlacetheCEentanglementdecaloverthe
existingentanglementdecal(Figure19).
12
RemovingtheStorage
Stands
Partsneededforthisprocedure:
4
Lynchpin(ProCore864)
8
Lynchpin(ProCore1298)
Procedure
1.Raisethemachine7.6to15.2cm(3to6inches)
offtheground.
2.Removethenutsandthelockwasherssecuring
thestoragestandstothemachine(Figure20).
g007303
Figure20
1.Storagestand
3.Nut
2.Lockwasher
3.Removethestoragestands.
4.Insertthelynchpins(includedinlooseparts)
intothestandpinsforstorage(Figure20).
Note:Usethestoragestandswheneveryou
removethemachinefromthetractionunit.
16
