Toro Sand Pro 2040Z - Air Cleaner and Spark Plug Service

G008748
3/4
1
2
3
4
5
6
Figure42
5.Applyalightcoatofcleanoiltothegasketofthenew
lter.
6.Installthenewlter,turningitbyhanduntilthegasket
contactsthelteradapter;thentightenit3/4turn
more.
Important:Donotovertightenthelter.
7.Checktheoillevel;refertoCheckingtheLevelofthe
EngineOil(page21).
8.Ifnecessary,addoilintothelltube.
9.Starttheengineandletitrunforabout3minutes,and
ensurethattherearenoleaks.
10.Stoptheengine.
11.Checktheoillevel,andaddoilifnecessary.
Note:Thelterholdssomeoil,sotheoillevelmay
decreasewheninstallinganewlter.
12.Installthedipstick.
13.Disposeoftheusedoilaccordingtolocalcodes.
ServicingtheAirCleaner
ReplacingtheAirFilter
ServiceInterval:Every200hours(moreoftenindusty
conditions).
Note:Changingtheairlterbeforeitisnecessaryonly
increasesthechanceofdirtenteringtheenginewhenthe
lterisremoved.
1.Parkthemachineonalevelsurface,stoptheengine,set
theparkingbrake,andremovethekey.
2.Releasethelatchessecuringtheair-cleanercovertothe
air-cleanerbody(Figure43).
1
2 3
4
G023446
Figure43
1.Latch(2)3.Cover
2.Airlter
4.Dirt-ejectionport
3.Removethecoverfromtheair-cleanerbody.
4.Removetheoldlter,andinstallthenewlter.
Note:Inspectthenewlterforshippingdamage,
checkingthesealingendofthelterandthebody.
Donotuseadamagedelement.Insertthenewlter
byapplyingpressuretotheouterrimoftheelement
toseatitinthecanister.Donotapplypressuretothe
exiblecenterofthelter.
Note:Donotcleantheusedelement,becauseitcan
damagetheltermedia.
5.Cleanthedirt-ejectionportlocatedintheremovable
cover.
6.Installthecoversothatthedirt-ejectionportpoints
downward.
