Toro TRX-250 - Replacing the Fuses

g000537
Figure49
1.Ventcaps3.Lowerline
2.Upperline
4.Iftheelectrolyteislow,addtherequiredamount
ofdistilledwater;refertoAddingWatertothe
Battery(page37).
AddingWatertotheBattery
Thebesttimetoadddistilledwatertothebatteryis
justbeforeyouoperatethemachine.Thisletsthe
watermixthoroughlywiththeelectrolytesolution.
1.Parkthemachineonalevelsurface,engagethe
parkingbrake,andlowertheboom.
2.Shutofftheengineandremovethekey.
3.Removethebatteryfromthemachine;referto
RemovingtheBattery(page35).
Important:Neverllthebatterywith
distilledwaterwhilethebatteryisinstalledin
themachine.Electrolytecouldspillonother
partsandcausecorrosion.
4.Cleanthetopofthebatterywithapapertowel.
5.Removetheventcapsfromthebattery(Figure
49).
6.Slowlypourdistilledwaterintoeachbatterycell
untiltheelectrolytelevelisuptotheUpperline
(Figure49)onthebatterycase.
Important:Donotoverllthebattery;
electrolyte(sulfuricacid)cancausesevere
corrosionanddamagetothechassis.
7.Wait5to10minutesafterllingthebattery
cells.Adddistilledwater,ifnecessary,untilthe
electrolytelevelisuptotheUpperline(Figure
49)onthebatterycase.
8.Installthebatteryventcaps.
ReplacingtheFuses
1.Parkthemachineonalevelsurface,engage
theparkingbrake(ifapplicable),andlowerthe
boom.
2.Shutofftheengineandremovethekey.
3.Removetheboltandaccesspanelontheright
sideofthemachine(Figure50).
g259092
Figure50
1.Bolt2.Accesspanel
4.Replaceanyblownfuses(Figure51).
g259093
Figure51
1.Fan—(15A,Model22984
only)
3.Accessory—(10A)
2.Fan—(15A)4.Mainpower(10A)
5.Installtheaccesspanelandsecureitwiththe
bolt(Figure50).
37
