Toro Workman GTX Series - Operating the Cargo Bed; Raising the Cargo Bed to the Dump Position

OperatingtheCargoBed
RaisingtheCargoBedtothe
DumpPosition
WARNING
Araisedbedcouldfallandinjurepersonsthat
areworkingbeneathit.
•Alwaysusetheproprodtoholdthebedup
beforeworkingunderthebed.
•Removeanyloadmaterialfromthebed
beforeraisingit.
WARNING
Drivingthemachinewiththecargobedraised
couldcausethemachinetotiporrolleasier.
Youcoulddamagethestructureofthecargo
bedifyouoperatethemachinewiththebed
raised.
•Operatethemachinewhenthecargobed
isdown.
•Afteremptyingthecargobed,lowerit.
CAUTION
Ifaloadisconcentratednearthebackofthe
cargobedwhenyoureleasethelatches,the
bedmayunexpectedlytipopen,injuringyou
orbystanders.
•Centerloadsinthecargobed,ifpossible.
•Holdthecargobeddownandensurethat
nooneisleaningoverthebedorstanding
behinditwhenreleasingthelatches.
•Removeallcargofromthebedbefore
liftingthebeduptoservicethemachine.
1.Pulltheleveronleft,insideofthecargobed
towardyouandliftthecargobedup(Figure13).
g034019
Figure13
1.Cargo-bedlever
2.Pulltheproprodintothedumppositiondetent
slottosecurethebedfordumping(Figure14).
g034021
Figure14
1.Servicepositiondetent
slot
3.Dumppositiondetentslot
2.Proprod
