InstallingtheBench
Cushion
Slidethebenchcushionontothepinsandlowerthe
cushion(Figure25).
g237190
Figure25
Lubrication
GreasingtheMachine
ServiceInterval:Every100hours/Yearly(whichever
comesrst)—Greasethebearings
andbushings.Greasethemachine
morefrequentlywhenusingitfor
heavy-dutyoperations.
GreaseType:No.2lithiumgrease
1.Usearagtowipethegreasettingcleansothat
foreignmattercannotbeforcedintothebearing
orbushing.
2.Withagreasegun,apply1or2pumpsofgrease
intothegreasettingsonthemachine.
3.Wipetheexcessgreaseoffthemachine.
Thegreasettingsarelocatedattheinnerendofthe
controlarms,thetie-rodballjoint,andtheouterend
ofthecontrolarms(Figure26andFigure27).
g034057
Figure26
g034058
Figure27
30
