g034044

Figure22

1.Rearliftingpoints

AccessingtheHood

RaisingtheHood

1.Liftupthehandleoftherubberlatchesoneach

sideofthehood(Figure23).

g034045

Figure23

2.Raisethehood.

ClosingtheHood

1.Gentlylowerthehood.

2.Securethehoodbyaligningtherubberlatches

ontothelatchanchorsoneachsideofthehood

(Figure23).

RemovingtheBench

Cushion

1.Pushthebenchcushionforwardtotheraised

position.

2.Slidethecushiontotheside,outofthepins,and

liftthecushionupward(Figure24).

g237191

Figure24
