Toro Workman GTX Series - Product Overview

ProductOverview
Controls
Becomefamiliarwithallthecontrolsbeforeyoustarttheengineandoperatethemachine.
ControlPanel
g033921
Figure4
1.Steeringwheel6.USBpowerpoint
2.Gear-shiftindicator
7.Parking-brakelever
3.Gear-shiftlever8.Chokecontrol
4.Hornbutton(Internationalmodelsonly)
9.Brakepedal
5.Keyswitch10.Acceleratorpedal
AcceleratorPedal
Usetheacceleratorpedal(Figure4)tovarythe
groundspeedofthemachine.Pressingdownthe
acceleratorpedalstartstheengine.Pressingthe
pedalfartherincreasesthegroundspeed.Releasing
thepedalslowsthemachine,andtheengineshutsoff.
Note:Themaximumforwardspeedis26km/h
(16mph).
BrakePedal
Usethebrakepedaltostoporslowthemachine
(Figure4).
CAUTION
Operatingamachinewithwornorincorrectly
adjustedbrakescanmayresultinpersonal
injury.
Ifthebrakepedaltravelstowithin25mm(1
inch)ofthemachineoorboard,adjustor
repairthebrakes.
