Toro Workman MDX - Servicing the Carbon Canister

Servicing the Carbon
Canister
Checking the Air Filter for the
Carbon Canister
Service Interval : Every 100 hours —Check the air
lter for the carbon canister .
Check the opening at the bottom of the air lter for the
carbon canister to ensure that it is clean and free of
debris and obstructions ( Figure 37 ).
g014998
Figure 37
1. Air lter opening (located inboard of the fuel tank and below
the carbon canister)
Replacing the Carbon-Canister
Filter
Service Interval : Every 200 hours —Replace the
carbon-canister lter .
1. Remove the barbed tting of the carbon-canister
lter from the hose at the bottom of the carbon
canister , and remove the lter .
Note: Discard the old lter .
g024478
Figure 38
1. Carbon-canister lter
3. Hose
2. Carbon canister
4. Fuel tank
2. Fully insert the barbed tting of the new
carbon-canister lter into the hose at the bottom
of the carbon canister .
