Pre-Maintenance

Procedures

PreparingtheMachinefor

Maintenance

1.Parkthemachineonalevelsurface.

2.Engagetheparkingbrake.

3.Shutofftheengineandremovethekey.

4.Emptyandraisethecargobed;refertoRaising

theCargoBedtotheServicePosition(page20).

LiftingtheMachine

DANGER

Themachinemaybeunstablewhenusing

ajack.Themachinecouldslipoffthejack,

injuringanyonebeneathit.

•Donotstartthemachinewhilethemachine

isonajack.

•Alwaysremovethekeyfromthekeyswitch

beforegettingoffthemachine.

•Blockthetireswhenthemachineis

supportedbyliftingequipment.

•Usejackstandstosupportthemachine

onceyouhaveliftedit.

Important:Wheneveryourunthemachinefor

routinemaintenanceand/ordiagnostics,ensure

thattherearwheelsofthemachineare25mm(1

inch)offtheground,withtherearaxlesupported

onjackstands.

•Theliftingpointatthefrontofthemachineis

locatedatthefrontoftheframe,behindthetowing

tongue(Figure23).

g034043

Figure23

1.Frontliftingpoint

•Theliftingpointattherearofthemachineis

locatedundertheaxletubes(Figure24).

g034044

Figure24

1.Rearliftingpoints
