Lubrication
GreasingtheMachine
ServiceInterval:Every100hours/Yearly(whichever
comesrst)—Greasethebearings
andbushings.Greasethemachine
morefrequentlywhenusingitfor
heavy-dutyoperations.
GreaseType:No.2lithiumgrease
1.Usearagtowipethegreasettingcleansothat
foreignmattercannotbeforcedintothebearing
orbushing.
2.Withagreasegun,apply1or2pumpsofgrease
intothegreasettingsonthemachine.
3.Wipetheexcessgreaseoffthemachine.
Thegreasettingsarelocatedattheinnerendofthe
controlarms,thetie-rodballjoint,andtheouterend
ofthecontrolarms(Figure31andFigure32).
g034057
Figure31
g034058
Figure32
GreasingtheFrontWheel
Bearings
ServiceInterval:Every300hours
Greasespecication:MobilgreaseXHP™-222
RemovingtheHubandRotor
1.Liftthefrontofthemachineandsupportitwith
jackstands.
2.Removethe4lugnutsthatsecurethewheel
tothehub(Figure33).
g033046
Figure33
1.Hub3.Lugnut
2.Wheel
3.Removetheange-headbolts(3/8x3/4inch)
thatsecurethebracketforthebrakeassembly
tothespindleandseparatethebrakefromthe
spindle(Figure34).
Note:Supportthebrakeassemblybefore
proceedingtothenextstep.
32
