AccessingtheHood
RaisingtheHood
1.Liftupthehandleoftherubberlatchesoneach
sideofthehood(Figure25).
g034045
Figure25
2.Raisethehood.
ClosingtheHood
1.Gentlylowerthehood.
2.Securethehoodbyaligningtherubberlatches
ontothelatchanchorsoneachsideofthehood
(Figure25).
RaisingandLoweringthe
SeatAssembly
Toraisetheseatassembly,pushtheseatassembly
forwarduntilitrestsonthesteeringwheel(Figure26).
Tolowertheseatassembly,pushtheseatassembly
rearwarduntilitseatsbackintotheoriginalposition
(Figure26).
g190066
Figure26
RemovingaBucketSeat
1.Pushtheseatassemblyforwardtotheraised
position(Figure26).
2.Slidetheseatassemblytothesideoutofthe
pins,andlifttheseatassemblyupward(Figure
27).
