Toro Z MASTER 2000 Series User Manual

i.Aligntherightangeoftheexhaust
shield(theangewith2holes)tothe
rearsurfaceofthelower-leftengine
guard(Figure7).
G018637
Figure7
HeatShieldInstallationonUSDomesticMower
ii.Alignthebottomedgeofthe
exhaust-shieldrightangetothe
bottomedgeoftheengineguard
(Figure7).
iii.Aligntheleftangeoftheexhaust
shield(theangewith1hole)tothe
surfaceofthesmall,angularareaof
thelower-leftengineguard.(Figure7).
Note:Ensuretheleftange(the
angewith1hole)oftheexhaust
shieldisushwiththeengine-guard
surface.
iv .Alignthetopedgeofthe
exhaust-shieldleftangeand
thetopedgeofthelower-leftengine
guardsothattheangeedgeandthe
guardedgeareparallel(Figure7).
v.Marktheoutlineofallholesinthe
exhaust-shieldangesontothe
lower-leftengineguard,andremove
theexhaustshieldfromtheengine
guard.
•ForInternational(TE)Mowers
i.Aligntheholesoftheexhaust-shield
rightange(theangewith2holes)
tothetwoleft-most-verticalslotsin
thelower-leftengineguard(Figure8).
G018638
1
Figure8
HeatShieldInstallationonInternational(TE)Mower
1.Flange-hex-headbolt(3/8x1inch)andNut(3/8inch)
ii.Alignthebottomedgeoftheright
angeoftheoftheexhaustshieldto
thebottomedgeoftheengineguard
(Figure8).
iii.Looselysecuretherightangeofthe
exhaustshieldtotheengineguard
with2ange-hex-headbolts(3/8x1
inch)and2angenuts(3/8inch).
iv .Aligntheleftangeoftheexhaust
shield(theangewith1hole)to
angularareaofthelower-leftengine
guard(Figure8).
Note:Ensurethattheleftange
(theangewith1hole)oftheexhaust
shieldisushwiththeengine-guard
surface.
v.Marktheoutlineoftheholeintheleft
angeoftheexhaustshieldontothe
lower-leftengineguard.
vi.Removethefastenersandexhaust
shieldfromtheengineguard.
3.Locatethecenterofthemarksonthelower-left
engine-guardsurface,andcenter-punchthelocations.
4.Drilla10mm(3/8inch)holeintheengineguardat
thecenter-punchmarkcreatedinstep3.
10

Toro Z MASTER 2000 Series Specifications

General

Engine Displacement	726 cc
Cutting Width	60 inches
Spindle Material	Cast
Drive System	Hydrostatic
Seat	Suspension
