Toro Z MASTER 2000 Series - Exhaust System Installation

3
InstallingtheTailpipe
Extension
Partsneededforthisprocedure:
1Tailpipeextension
1
Washer-headscrew(#8x1/2inch,self-threading)
Procedure
Installthetailpipeextensionasfollows:
1.Locatethemufertailpipeatthelowerleftcornerof
theengine.
Note:Ifyouneedadditionalroomtoinstallthe
tailpipeextension,dothefollowingsteps:
A.Removethe3angenutsthatsecurelower-left
engineguardtothemachine(Figure5).
Note:Retaintheseparts.
4
3
5
3
62
4
3
3
5
61
G018372
Figure5
Lower-LeftEngineGuard
1.Lower-leftengineguard
(USdomesticmowers)
4.Flangenut
2.Lower-leftengineguard
(Internationalmowers)
5.Carriagebolt(center
engineguard)
3.Carriagebolt(frontmount
point)
6.Mufertailpipe
B.Removethe2carriageboltsatthefront-mount
pointandthelower-leftengineguard.(Figure5).
Note:Retaintheseparts.Donotremovethe
carriageboltatthecenterengineguard.
2.Measure19mm(3/4inch)alongtheoutsideofthe
mufertailpipe,fromtheoutletendmovingtowardthe
muferasillustratedinFigure6,andmarkthesurface
ofthetailpipeatthismeasurement.
