Toro Z MASTER 2000 Series User Manual

Important:Ensurethatthedrillbitdoes
notcontactthemuferwhendrillingthe
heat-shield-mountingholeinthelower-leftengine
guard.
5
InstallingtheExhaustShield
Partsneededforthisprocedure:
1Exhaustshield
3
Flange-hex-headbolt(3/8x1inch)
3
Nut(3/8inch)
Procedure
Installtheexhaustguardonthelower-leftbumperasfollows:
1.Aligntheholeoftheexhaust-guardleftangetothe
holeinthesmall,angularareaoftheengineguardas
illustratedinFigure9forDomestic(US)mowersor
inFigure10forInternational(TE)mowers.
G018364
621
1
2
3
4
4
5
Figure9
Heat-ShieldInstallationonUSDomesticMower
1.Lower-leftengineguard4.Nut(3/8inch)
2.Exhaustshield
5.Flangenut(lower-left
engineguard,
back-mountingpoint)
3.Flange-hex-headbolt(3/8
x1inch)
6.Tailpipeextension
11

Toro Z MASTER 2000 Series Specifications

General

Engine Displacement	726 cc
Cutting Width	60 inches
Spindle Material	Cast
Drive System	Hydrostatic
Seat	Suspension
