ProcedureDescription
Qty.
Use
Weight-mountbracket1
Carriagebolt(5/16x3/4inch)
2
Flangenut(5/16inch)
2
Frontweight3
Bolt(3/8x1inch)
6
Lockwasher6
Flatwasher6
13
Flangenut(3/8inch)
3
Installtheweights.
14
Nopartsrequired
–
Checkthetirepressure.
Note:Determinetheleftandrightsidesofthemachinefromthenormaloperatingposition.
1
PreparingtheMower
NoPartsRequired
Procedure
Performthefollowingproceduretopreparethemowerfor
attachingtheblowerandbaggerkit.
1.DisengagethePTO,movethemotion-controllevers
totheNEUTRALlockedposition,andsettheparking
brake.
2.Shutofftheengine,removethekey,andwaitforall
movingpartstostopbeforeleavingtheoperating
position.
3.Repairallbentordamagedareasofthemowerdeck
andreplaceanymissingparts.
4.Cleanthemowerofanydebrisonthedeckorrearpart
ofthemowertoeaseinstallation.
2
InstallingtheSideBumpers
andSupportBrackets
Partsneededforthisprocedure:
1
Leftbumper
1
Leftframe-supportbracket
1Rightbumper
1
Rightframe-supportbracket
6
Carriagebolt(3/8x1-1/4inches)
6
Flangenut(3/8inch)
Procedure
1.Removetheleftandrightbumpersasfollows:
A.Removethenutsandboltssecuringtheleftside
bumperandmufershieldtothechassisand
centerengineguardasshowninFigure4.
6

Toro Z MASTER 2000 Series Specifications

General

Engine Displacement	726 cc
Cutting Width	60 inches
Spindle Material	Cast
Drive System	Hydrostatic
Seat	Suspension
