2. PRINTER SETUP ENGLISH VERSION EO1-33097
2.6 Opening/Closing the Top Cover
E2-6
2.6 Opening/Closing the
Top Cover
When opening or closing the Top Cover, please be sure to follow the
instructions below.
To open the Top Cover:
1. Open the Top Cover while pulling the Lock Release Portions as
indicated by the arrows.
To close the Top Cover:
1. Close the Top Cover.
WARNING
!
To avoid injury, be careful
not to trap your fingers while
opening or closing the cover.
CAUTION!
1. Be careful not to touch the
Print Head Element when
opening the Top Cover.
Failure to do this may
cause missing dots by
static electricity or other
print quality problems.
2. Do not cover the Cover
Open Sensor with your
finger, hand, etc. Doing so
may cause the sensor to
wrongly detect a cover
close state.
NOTE:
Be sure to close the Top Cover
completely. Failure to do this
may affect the print quality.
Top Cover
Lock Release Portion
