Toshiba B-FV4D SERIES - Self Print Test and Dump Mode

2. PRINTER SETUP ENGLISH VERSION EO1-33097
2.8 Media Sensor Calibration, Self Print Test, and Dump Mode Utilities
E2-16
2.8.2 Self Print Test and
Dump Mode
1. Turn off the printer power and install a full width media roll
(104mm/4inch) in the printer.
2.
Press and hold the [FEED] Button while turning on the printer. The
status lamps (LED 1 and LED 2) will light up in the following order:
Orange  Green  Other colour sequences
3. Release the [FEED] Button when LED 1 lights in orange and LED 2
lights in green.
4. Press the [FEED] button.
5. The printer prints the self print test, and then enters Dump Mode.
6. To return to Online operation, turn the printer off, then on again.
Print test label sample
NOTE:
The following commands will
have no effect the test print. D,
AX, XS, Z2;1, Z2;2 (only the AY
command will)
B
-
F
V4
D
-
G
P
RINTER INFO.
PROGRAM VERSION 05MAY2014B-FV4 V1.1J
TPCL VERSION 28APR2014 V1.0K
CG VERSION 27FEB2014 V1.0
CHINESE VERSION 27FEB2014 V1.0
CODEPAGE VERSION 27FEB2014 V1.0
BOOT VERSION V1.1C
KERNEL FONT VERSION 1.0.03
WLAN MODULE [Installed]
BLUETOOTH MODULE [Installed]
[PARAMETERS]
HW DETECT [0000000000000000]
TONE ADJUST(T) [---]
TONE ADJUST(D) [+00]
FEED ADJUST [+0.0mm]
CUT ADJUST [+0.0mm]
BACKFEED ADJUST [+0.0mm]
X-COORD. ADJUST [+0.0mm]
CODEPAGE [PC-850]
ZERO SLASH [0]
FEED KEY [FEED]
EURO CODE [B0]
CONTROL CODE [AUTO]
MAXI CODE SPEC. [TYPE 1]
SENSOR SELECT [Transmissive]
PRINT SPEED [5ips]
FORWARD WAIT [ON]
AUTO CALIB. [OFF]
MULTI LABEL [OFF]
AUTO THP CHK [OFF]
BASIC [OFF]
Reserved item1
Reserved item2
FLASH ROM [16MB]
SDRAM [32MB]
USB SERIAL NUM. [000000000001]
[INFORMATION]
INFORMATION [B-FV4D-GS12-QM-R]
[2303A000006]
TOTAL FEED1 [0.00km]
TOTAL FEED2 [00000cm]
[0000.0inch]
TOTAL PRINT [0.00km]
TOTAL CUT [0]
[RS-232C]
BAUD RATE [9600]
BIT [8]
STOP BIT [1]
PARITY [None]
FLOW [XON/XOFF]
