APPENDIX 1 SPECIFICATIONS ENGLISH VERSION EO1-33097
A1.2 Options
EA1-3
A1.2 Options
Option Name Type Description
Cutter module B-FV204D-F-QM-R A cutter unit that fully cuts (separates) the printed
media.
B-FV204D-P-QM-R A cutter unit that partial cuts (does not fully
separate) the printed media.
Peel-off module B-FV904D-H-QM-R This module enables the printer to strip the
backing paper from the print labels and present
the striped labels on-demand (one by one) by
detecting the presence or removal of a label from
the peel bar.
External media stand B-FV904-PH-QM-R When this option is attached to the printer, a
media roll with an outer roll diameter up to
203mm (8”) and inner core diameter of 76.2mm
(3”) can be used.
Wireless LAN ki
B-FV700-WLAN-QM-R This interface kit enables wireless LAN (WLAN)
communication.
Bluetooth interface ki
B-FV704D-BLTH-QM-R This interface kit enables Bluetooth
communication.
A1.3 Media
Please make sure that the media to be used is approved by TOSHIBA TEC CORPORATION. The warranties do
not apply to problems caused by using media that is not approved by TOSHIBA TEC CORPORATION.
For information regarding TOSHIBA TEC CORPORATION-approved media, please contact a TOSHIBA TEC
CORPORATION authorised representative.
A1.3.1 Media Type
The table below shows the size and shape of the media that can be used on this printer.
NOTE:
The above options are available from your nearest TOSHIBA TEC CORPORATION representative or TOSHIBA TEC
CORPORATION Head Quarters.
Feed Direction
Black Mark
(on reverse side)
Tag paper
Cut position
Black Mark
(on reverse side)
Label
To Next Page
