APPENDIX 1 SPECIFICATIONS ENGLISH VERSION EO1-33097
A1.3 Media
EA1-6
The figure below shows the effective print area on the media.
NOTES:
1. Be sure not to print on the 1.5-mm wide area from the media edges (shaded area in the above figure).
2. The centre of media should be positioned at the centre of the print head.
3. Print quality is not guaranteed within 3 mm from the print head stop position (including 1-mm slow-up.)
4. Average print (black) rate should be 15% or less. For barcode print area, the print rate should be 30% or less.
5. Line weight should be 3 to 12 dots.
Guaranteed print area
1mm
1mm
1.5mm from the right edge of media
1.5mm from the left edge of media
Media feed direction
Media width
(Backing paper width is not included.)
Start line
