2. SUPPLY SPECIFICATIONS EO10-33013B
2.1 MEDIA
2- 1
2. SUPPLY SPECIFICATIONS
Information regarding the supply specifications contained in Product Description is essential to service
engineers. Detail specifications and other information on the media and ribbon are described in Supply
Manual by model. It is issued by and sent from TOSHIBA TEC H.Q (Sales Division) upon release of
new model or manual's revision. When purchasing the supplies locally, be sure to refer to the Supply
Manual for details. Use of non-specified media may shorten the print head life and result in problems
with bar code readability or print quality. Be sure to read carefully and understand the Supply Manual
since it also includes the details about notes, precision of the print start position, limitations on printing,
etc. When selling the products to VARs, instruct them to buy media and ribbons that the substances
described in the following precautions are not included
2.1 MEDIA
[B-SX4T]
(Unit: mm)
Cut mode
Label dispensing mode
Item
Batch mode Strip mode
Rotary cutter (*2) Swing cutter
Label 10.0 – 1500.0 25.4 – 1500.0 3”/sec., 6”/sec.: 38.0 - 1500.0 38.0 – 1500.0
Media pitch
Tag 10.0 – 1500.0 ---- 3”/sec., 6”/sec.: 30.0 – 1500.0 25.4 – 1500.0
Label length 8.0 – 1498.0 23.4 – 1498.0 3”/sec., 6”/sec.: 32.0 – 1494.0 25.0 – 1494.0(*1)
Width including backing paper (See NOTE 5.) 30.0 – 112.0 50.0 – 112.0 30.0 – 112.0
Label width (See NOTE 5.) 27.0 – 109.0
Gap length 2.0 – 20.0 6.0 – 20.0
Black mark length (Tag paper) 2.0 – 10.0
Effective print width 10.0 – 104.0±0.2
Label 6.0 – 1496.0 21.4 – 1496.0 3”/sec., 6”/sec.: 30.0 - 1492.0 23.0 – 1492.0
Effective print length
Tag 8.0 – 1498.0 ---- 3”/sec., 6”/sec.: 28.0 – 1498.0 23.4 – 1498.0
Print speed up/slow down area 1.0
Label 0.13 – 0.17
Thickness
Tag 0.15 – 0.29
Max. effective length for on the fly issue 1361.0
Maximum outer roll diameter Ø200 (See NOTE 9.)
Roll direction Inside
Inner core diameter Ø76.2±0.3
[B-SX5T]
(Unit: mm)
Cut mode
Label dispensing mode
Item
Batch mode Strip mode
Rotary cutter Swing cutter
Label 10.0 – 1500.0 25.4 – 1500.0 38.0 - 1500.0 38.0 – 1500.0
Media pitch
Tag 10.0 – 1500.0 ----
3”/sec., 5”/sec.: 30.0 – 1500.0
8”/sec.: 38.0 – 1500.0
25.4 – 1500.0
Label length 8.0 – 1498.0 23.4 – 1498.0 32.0 – 1494.0 25.0 – 1494.0(*1)
Width including backing paper (See NOTE 5.) 30.0 – 140.0 50.0 – 140.0 30.0 – 112.0 30.0 – 140.0
Label width (See NOTE 5.) 27.0 – 137.0 27.0 – 109.0
Gap length 2.0 – 20.0 6.0 – 20.0
Black mark length (Tag paper) 2.0 – 10.0
Effective print width 10.0 – 128.0±0.2
Label 6.0 – 1496.0 21.4 – 1496.0 30.0 - 1492.0 23.0 – 1492.0
Effective print length
Tag 8.0 – 1498.0 ----
3”/sec., 5”/sec.: 28.0 – 1498.0
8”/sec.: 36.0 – 1498.0
23.4 – 1498.0
Print speed up/slow down area 1.0
Label 0.13 – 0.17
Thickness
Tag 0.15 – 0.29
Max. effective length for on the fly issue 749.0
Maximum outer roll diameter Ø200 (See NOTE 9.)
Roll direction Inside
Inner core diameter Ø76.2±0.3

Toshiba B-SX5T Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Interface	Parallel, USB
Optional Interfaces	Wireless LAN
Memory	4 MB Flash
Print Speed	Up to 152.4 mm/sec (6 ips)
