1 Setting up Network Server
22 Setting up NetWare Print Server
2
Enter the NDS queue name in the “Queue Name” field and the user
name in the “Queue User Name” field. Then click [Finish].
y The Select Printer Drivers dialog box appears.
The NDS queue must be created.
3
Select the printer drivers to be installed in the “Printer Drivers” list
at each OS tab, and click [Continue].
y The Information dialog box appears.
4
Click [OK].
y It takes about 60 seconds to complete the creation of the NDPS Printer object.
5
Double-click the NDPS Printer object that you created.
y The NDPS Printer dialog box appears.
6
Click [NDPS Remote Printer Management].
7
Check the “Install to workstation in this container” and click
[Update].
8
Click [OK] to close the NDPS Printer dialog box.
Setting up NDPS Using TOSHIBA NDPS Gateway
The TOSHIBA NDPS Gateway mechanism employs several components, notably the NDPS
Manager, NDPS Broker, and NDPS Printer Agent. The following figure illustrates the communi-
cation flow between these objects.
1
The NetWare printer can be discovered in two ways:
y The printer is automatically discovered by the TOSHIBA NDPS Gateway.
You add it manually to the NDPS Manager, which resides on the same NetWare file
server as the TOSHIBA NDPS Gateway.
2
When an end-user attempts to add a NDPS printer, the client que-
ries the NDPS Brokers to identify all available NDPS printers.
NetWare File Server
End UserAdministrator
1
1
6
NDPS Broker
Printer Agent
NDPS Manager
5
2
3
4
To Next Page
