Toshiba HFC R407C - Outdoor Unit - Inverter Assembly

14
Parts specification
Outdoor unit
Specification of outdoor unit inverter assembly parts
Model name MAR-F105HTM8-PE
Power supply 380-415 V, 3 phase, 50 Hz
PC board assembly PCB (IPDU) MCC-1342
PC board assembly PCB (noise filter) MCC-1366
PC board assembly PCB (interface) MCC-1223
PC board assembly PCB (communication) MCC-1387
Fan motor capacitor 8 µF/450 V AC
Electrolytic capacitor 2200 µF/400 V
Power supply terminal plate L1, L2, L3 600 V AC, 60 A, 3 pole
Transformer Interface TT01
Magnetic contactor Inverter side FMCa - 1S
Magnetic contactor Fixed side FC - 3
Reactor CH - 25 - 2FK
Fuse 6 A 500 V AC
Fuse 20 A 600 V AC
Fuse 3.15 A 250 V AC
Fuse 6.3 A 250 V AC
Fuse 20 A 250 V AC
Fuse 10 A 250 V AC
Thermistor (PTC)
Relay 15 A, 240 V AC
Note:
Specifications are subject to change without notice.
