16
Construction view
Outdoor unit
Refrigerant pipe connecting port
(Gas suction side) braze connection (ø 28.6)
Refrigerant pipe connecting port
(Liquid side) flare connection (ø 15.9)
Refrigerant pipe connecting port (gas
discharge side) flare connection (ø 19.0)
Knock outs on
both sides of unit
Details of piping connections
Foundation dimensions
Slot pitch
Fixing bolt pitch
Grounding part of bottom plate
4-15 x 20 (Slot)
Fixing bolt positions
MAR-F105HTM8-PE
Dimensional drawings
Grounding part of bottom plate
All dimensions in mm
790755
990
700
630
80
80
750
1700
1582
700
88
90
110
601
568
500
4-60 x 150 slot
(for transport)
3-ø 20 cable gland knock outs
ø 32 cable gland knock outs
ø 25 cable gland knock outs
275
315
1146068
4 - ø 25
drain holes
Pipe outlet
(bottom)
