3 Parts Rating
3-1. Outdoor Unit (208/230V model: MMY-MAP0726FT2P-UL)
No
Name Model Specification
MMY-MAP0726FT2P-UL
1
Compressor
DA421A3TB-20M1
Output:2.1kW×2
○
2
4-way valve coil SHF
AC208-230V 60Hz
3
2-way valve coil VPV
AC208-230V 60Hz
SV3B, 11, 14, 15
AC208-230V 60Hz
SV2, 6, 3A, 3C, 3D, 3E
3
2-way valve coil FQ-D640
AC208-230V 60Hz
SV5, 41, 42
4
Pulse motor valve coil
PAM, BA2YGTF-1
DC12V
4
Pulse motor valve coil
HAM, BD28TF-2
DC12V
5
High-presure SW
ACB-4UB106W
OFF:541psi (3.73MPa) ON:421psi (2.9MPa)
6
Pressure sensor
(For high pressure)
NSK-BH038F-U532
0.5～4.3V/0~541psi (3.73MPa)
7
Pressure sensor
(For low pressure)
NSK-BH010F-U532
0.5～3.5V/0~142psi (0.98MPa)
8
Fan motor
WDF-620A1000-1
DC280-340V
9
Case heater (For comp.)
AC240V/29W
10
Case heater (For accum.)
AC240V/55W
11
Fusible plug
163.4°F (73℃)
TEV2-way valve coil
