3-3. Multi port
FS Unit (Model: RBM-Y0611F4PUL, RBM-Y0611F6PUL)
F4PUL F6PUL
SVS, SVD
○ ○
SVSS
○ ○
SVDD
○ ○
2
2-way valve
VPV-1204DQ55
SVS, SVD
－
○ ○
SVSS
○ ○
SVDD
○ ○
4
PMV (Pulse motor valve) coil DC12V
○ ○
5
PMV (Pulse motor valve)
－
○ ○
6
TCS sensor
○ ○
CAM-BD14TF-1
－
3
2-way valve VPV-122DQ1
－
CAM-MD12TF-17
1 2-way valve coil
VPV-MOAQ1843A0
AC208-230V 60Hz
No. Parts Name Model Specification
RBM-Y0611
3-4. Single port FS unit (Long piping model)
(Model: RBM-Y0384FUL, RBM-Y0614FUL, RBM-Y0964FUL)
Y0384FUL
Y0614FUL
Y0964FUL
SVS ○ ○ ○
SVSS ○ ○ ○
SVDD ○ ○ ○
SVD ○ ○ ○
SVS ○ ○ ○
SVD ○ ○ ○
SVSS ○ ○ ○
SVDD ○ ○ ○
4 PMV (Pulse motor valve) coil DC12V
○ ○ ○
－ ○ ○
－ ○
6 TCS sensor
0.24" (∅6) size
lead wire length: 19.7" (500 mm)
○ ○ ○
No. Parts Name Model Specification
RBM-
1 2-way valve coil VPV-MOAQ1843A0 AC208/230V 60Hz
2 2-way valve VPV-1204DQ55
－
3 2-way valve VPV-122DQ1
－
CAM-MD12TF-17
5 PMV (Pulse motor valve)
CAM-BD14TF-2
CAM-BD18TF-1
－
0.24" (∅6) size
lead wire length: 19.7" (500 mm)
