17-4. Single port FS unit RBM-
Y0383FUL, RBM-Y0613FUL
Y0613
only
3
2
4
6
7
5
1
Location
No.
Part No. Description RBM-Y0383FUL RBM-Y0613FUL
1
1
2
3
4
5
6
7
43149418
43149417
4316V338
4314N046
4314N125
43F60029
43135013
43135017
BODY ASSY, SERVICE
BODY ASSY, SERVICE
PC BOARD ASSY, MCC-1431
COIL, SOLENOID, AC208-230 60Hz
2WAY, COIL, ASSY
FILTER,NOISE
CABLE ASSY, POWER
CABLE ASSY
1
1
3
1
1
1
1
1
1
4
1
1
1
1
!
!
!
!
!
!
means highly important parts to maintain product safety.
