– 16 –
Weight centre and weight
Weight centre of an outdoor unit
No. Model type X (mm) Y (mm) Z (mm) Mass (kg)
(A)
MAP080
500 390 645MAP100
MAP120
(B)
MAP140
605 350 700 329
MAP160
Z
X
Z
X
Y
Y
(A)
(B)
Anchor bolt position
700
Anchor bolt position
920
Anchor bolt position
755
Anchor bolt position
755
H/P 242
C/O 241
