6. List of OPC Items
74
Table 6.1 List of OPC items
Prefix
Item Name
Description
Data Type
Mode
Tcnet
RasInfo.Mac#mmm.Stack#sA.OptPort#p.
NumOfPackets
HUB(#mmm) stack(#s) optical port(#p) Number of received
packets (A System) (*1)
[Stack: #0 - #3] [Port: #1 - #8]
VT_UI2 RO
RasInfo.Mac#mmm.Stack#sA.ElePort.
NumOfPackets
HUB(#mmm) stack(#s) Electrical port Number of received
packets (A System) (*1)
VT_UI2 RO
RasInfo.Mac#mmm.Stack#sB.OptPort#p.
NumOfPackets
HUB(#mmm) stack(#s) optical port(#p) Number of received
packets (B System) (*1)
VT_UI2 RO
RasInfo.Mac#mmm.Stack#sB.ElePort.
NumOfPackets
HUB(#mmm) stack(#s) Electrical port Number of received
packets (B System) (*1)
VT_UI2 RO
RasInfo.Mac#mmm.RasArea.HealthyCounter
Healthy counter of a RAS information area
VT_UI2
RO
TimeInf#d
Time information [#0 - #1] (*3)
VT_UI4
RO
Opc
LocalNodeAddr
Own node's address (node address on TC-net side)
VT_UI2
RO
LocalNodeStatus
Own node's state (ONLINE/STANDBY/BACKUP etc.)
VT_UI2
RO
ParentNodeAddr#d
Parent node's address for maximum 9 nodes [#0 - #8]
VT_UI2
RO
ParentNodeStatus#d
Parent node's state for maximum 9 nodes [#0 - #8]
VT_UI2
RO
ChildNodeAddr
Child node's address
VT_UI2
RO
ChildNodeStatus
Child node's state
VT_UI2
RO
BackupNodeAddr#d
Parent node's address during backing up for maximum 9 nodes
[#0 - #8]
VT_UI2 RO
OperationTime
Running time
VT_UI4
RO
HealthyCounter
Healthy counter
VT_UI2
RO
DualControl
Control dual state
(=1 : STANDBY request / =0 : STANDBY release request)
VT_UI2 R/W
ScanTalkerStatus
Duplicate state of talker blocks
VT_UI2
RO
Client.HealthyCounter#mmm
Client Healthy Counter [#000 - #127]
= 1 - 65535 : check it
= 0 : not check
VT_UI2 R/W
Client.Abnormal#mmm
Client diagnosis is abnormal [#000 - #127]
VT_BOOL
RO
Client.AbnormalDetect
Client abnormal detection state
(AND of a diagnosis result for 128 clients)
VT_BOOL RO
ParentTalkerStatus#d
Parent node's duplicate state of talker blocks [#0 - #8]
VT_UI2
RO
OpcSrv.MemUsed.Current
Quantity of memory use of OPC server (Current value)
VT_UI4
RO
OpcSrv.MemUsed.Average
Quantity of memory use of OPC server (Average value)
VT_UI4
RO
(*1) : JTNI (TC-net100) Only , (*2) : JTGI (TC-net1G) Only , (*3) : JTGI (TC-net1G) and JTNI (PCI Express Card) Only
R/W : Read/Write , RO : Read Only
Reference:
Show a meaning of a place described like "[#0000～#nnnn / #gggg]" in lists in the
following.
- #nnnn : Case of JTNI (TC-net100)
- #gggg : Case of JTGI (TC-net1G)
Reference
:
As for the details about "Quantity of memory use of OPC server", please refer to 10.1.
