6. List of OPC Items
75
RAS function "Quantity of memory use of OPC server".
Reference
:
After OPC server V01.60, the following items are deleted.
- Tcnet.ReportRasUsage
- Tcnet.ResetJtni
- Opc.DiagStatus
Reference
:
About data structure of a TC-net related item, please refer to an TC-net PCI Bus Card
Support Software User's Manual.
Reference
:
In a "Opc.LocalNodeStatus", it is set in the next value.
0 : INIT, 1 : PRE-ONLINE, 2 : ONLINE,
3 : STANDBY, 4 : BACKUP, 5 : DOWN
Reference
:
In a "Opc.ParentNodeStatus#d", it is set in the next value.
0 : INIT, 1 : PRE-ONLINE, 2 : ONLINE,
3 : STANDBY, 4 : BACKUP, 5 : DOWN,
6 : DIAG_ERR, 7 : JTNI/JTGI_ERR
DIAG_ERR is set in the case of own node's JTNI/JTGI is normal, and parent node's
JTNI/JTGI unhealthy or parent node's OPC server unhealthy.
About JTNI/JTGI_ERR, At the time of own node's JTNI/JTGI abnormal, parent node's
state is set JTNI/JTGI abnormal.
Reference
:
Station(#mmm) representation alarm (RasInfo.Mac#mmm.Alarm) is logical sum of
representation alarm of slot 1-7 (RasInfo.Mac#mmm.Slot#d.Alarm).
