1. Hardware Renewal
8
Table 1.6 10M Ethernet Control LAN Renewal Items for TOSDIC-AS
Item TOSDIC-AS CIEMAC-DS Remarks
1 Transceiver branch
equipment
DELNI UTHB1 Note 1)
2 Transceiver VXVRU1
VXVRU12
UTTN1
UTMT1(Multiport)
UTOT1(Optical)
3 Optical repeater Note 2) VSHRU1 UTOR1
VSHRU3 Not supported For long
distance
4 Electric repeater VSHRU2, VSHRU4 UTRP1
5 Optical transceiver/
star coupler
VOTRU1, VOTRU12
VFOSU1
Not supported Used as an
optical repeater
6 Transceiver cable
(between STN and DELNI)
SHC bus dedicated
cable
Twisted pair cable
7 Transceiver cable
(between DELNI and
Transceiver)
SHC bus dedicated
cable
10BASE-5 AUI cable
8 Coaxial cable 10BASE-5 Coaxial
cable
10BASE-5 Coaxial
cable
Can still be
used
9 Optical fiber cable Note 3) CT-G3004S-05-NME CT-G3004S-05-NME Short wave
length
CT-G0704L-05-NME Not supported Long wave
length
Note 1) If you use a hub for DELNI instead, you need to be careful when you build your network system since a hub
is counted as a repeater. (DELNI is a transceiver branch device, which doesn’t have the repeat function.
Therefore, it is not counted as a repeater.)
Note 2) There is no long-distant optical repeater (as in the Ethernet specifications). If the optical repeating
distance is more than 2 km, consult with us.
Note 3) The existing optical fiber code (short wave length) and optical connector can still be used. If so, check the
attenuation and clean the optical connector.
