Toshiba TOSDIC-CIE DS Manual

1. Hardware Renewal
9
Table 1.7 100M Ethernet Control LAN Renewal Items for TOSDIC-AS
Item TOSDIC-AS CIEMAC-DS Remarks
1 Transceiver branch
equipment
DELNI UHSH1
UHHB1
Note 1)
2 Transceiver VXVRU1
VXVRU12
UHOE1
(FX-TX conversion
module)
3 Optical repeater Note 2) VSHRU1 Not supported
VSHRU3 Not supported
4 Electric repeater VSHRU2, VSHRU4 Not supported
5 Optical transceiver/
star coupler
VOTRU1, VOTRU12
VFOSU1
Not supported
6 Transceiver cable
(between STN and DELNI)
SHC bus dedicated
cable
Twisted pair cable
7 Transceiver cable
(between DELNI and
Transceiver)
SHC bus dedicated
cable
Not supported
8 Coaxial cable 10BASE-5 Coaxial
cable
Not supported Can still be used
9 Optical fiber cable Note 3) CT-G3004S-05-NME Not supported Short wave
length
CT-G0704L-05-NME CT-G62.5/125-05-N
ME
Long wave
length
Note 1) You can add one 100BASE-FX port by adding an optional module.
Note 2) There is no long-distant optical repeater. If the optical repeating distance is more than 2 km, consult with
us.
Note 3) As a rule, the existing optical fiber cable, optical fiber code, and optical connector can not be used. Please
use ones that comply with the specifications.
