(2) Renewal of TOSDIC-AD
To renew a network of TOSDIC-AD, you need to renew or add the following items.
Table 1.8 10M Ethernet Control LAN Renewal Items for TOSDIC-AD
Item TOSDIC-AD CIEMAC-DS Remarks
1 CBM tap CBT-20-20-4F/2F
HMT
UTHB1 Hub
UTTN1 (Multiport) Transceiver
2 Optical repeater Note 1) HMR-100, UMRU1A UTOR1
UMRU15 Not supported
3 Electric repeater UMRU20 UTRP1
4 Star coupler VFOSU1 Not supported Used as an
optical repeater
5 Drop cable/panel cable 3C, 5C coaxial cable Twisted pair cable
10BASE-5 AUI cable
When hubs are
used
6 Trunk cable 7C, 10C coaxial
cable
10BASE-5 coaxial
cable
7 Optical fiber cable Note 2) CT-G3004S-05-NME CT-G3004S-05-NME Short wave
length
CT-G0704L-05-NME Not supported Long wave
length
Note 1) There is no long-distant optical repeater (as in the Ethernet specifications). If the optical repeating
distance is more than 2 km, consult with us.
Note 2) The existing optical fiber code (short wave length) and optical connector can still be used. If so, check the
attenuation and clean the optical connector.
To Next Page
