1. Hardware Renewal
11
Table 1.9 100M Ethernet Control LAN Renewal Items for TOSDIC-AD
Item TOSDIC-AD CIEMAC-DS Remarks
1 CBM tap CBT-20-20-4F/2F
HMT
UHSH1
UHHB1
UHOE1
(FX-TX conversion
module)
Note 1)
2 Optical repeater Note 2) HMR-100, UMRU1A Not supported
UMRU15 Not supported
3 Electric repeater UMRU20 Not supported
4 Star coupler VFOSU1 Not supported
5 Drop cable/panel cable 3C, 5C coaxial cable Twisted pair cable
6 Trunk cable 7C, 10C coaxial
cable
Not supported
7 Optical fiber cable Note 3) CT-G3004S-05-NME Not supported Short wave
length
CT-G0704L-05-NME CT-G62.5/125-05-N
ME
Long wave
length
Note 1) For a hub, you can add one 100BASE-FX port by adding an optional module.
Note 2) There is no long-distant optical repeater. If the optical repeating distance is more than 2 km, consult with
us.
Note 3) As a rule, the existing optical fiber cable, optical fiber code, and optical connector can not be used. Please
use ones that comply with the specifications.
