The behavior of BF LED
Module Status
Color and behavior
Meaning
OFF The device is powered off
Green/Red blinking
Power up testing
Green flashing In combination with other LEDs : DCP manual identification phase /
DCP flash mode
Green ON
The device is ready and operational
Red Single flash No connection to the PROFINET Controller
Red flickering
The option has detected a communication error (
err8
)
Red ON The option has detected a option module error (
e-23
)

The behavior of SF LED
Network Status
Color and behavior Meaning
OFF
The option does not have IP address or powered off
Green/Red blinking Power up testing
Green flickering In combination with other LEDs: DCP manual identification phase /
DCP flash mode
Green flashing 3 times All ports are unplugged, but the card has an IP address
Green flashing 4 times
Error: duplicate IP address
Green flashing 5 times The card is performing a DHCP sequence
Green ON
At least a port is connected and has a valid IP address.
Red ON General error on the module
If the communication card operates as a Modbus TCP server only, LNK LEDs work as follows.

The behavior of LNK LED for Modbus TCP
Link Activity
Color and behavior
Meaning
OFF No link
Green Blink
Network Activity at 100 Mbps
Green ON Link established at 100 Mbps
Yellow Blink
Network Activity at 10 Mbps
Yellow ON Link established at 10 Mbps

Toshiba Tosvert VF-S15 Specifications

General

Category	Inverter
Control Method	V/f control, Sensorless vector control
Cooling Method	Forced air cooling
Model	Tosvert VF-S15
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication Options	Modbus RTU
Overload Capacity	150% for 1 minute
Braking Unit	Built-in braking transistor
Output Voltage	3-Phase, same as input voltage
Operating Temperature	-10 to +50°C (14 to 122°F)
Storage Temperature	-20 to 65°C (-4 to 149°F)
Humidity	5 to 95% RH (non-condensing)
Altitude	Up to 1000m above sea level
Input Voltage	3-Phase 200 to 240 VAC, 3-Phase 380 to 480 VAC
Weight	Varies depending on model (e.g., 0.8 kg to 16 kg)
