6.7.
PROFIdrive parameter (PNU)
PNU
R/W
data type
Note
915
R
Array [6]
Unsigned16
PNU 915, IND 0 = the inverter parameter
c001
PNU 915, IND 1 = the inverter parameter c002
PNU 915, IND 2 = the inverter parameter c003
PNU 915, IND 3 = the inverter parameter c004
PNU 915, IND 4 = the inverter parameter c005
PNU 915, IND 5 = the inverter parameter
c006
916
R
Array [6]
Unsigned16
PNU 916, IND 0 = the inverter parameter
c021
PNU 916, IND 1 = the inverter parameter c022
PNU 916, IND 2 = the inverter parameter c023
PNU 916, IND 3 = the inverter parameter c024
PNU 916, IND 4 = the inverter parameter c025
PNU 916, IND 5 = the inverter parameter
c026
922
R
Unsigned16
Telegram selection ( same as the inverter parameter
c152
)
1, 100, 101, 102
923
R
Array [156]
Unsigned16
List of all the parameters for signals
930
R
Unsigned16
Operating mode
1:
supports the speed control mode and the speed setpoint
channel comprises RFG functionality.
944
R
Unsigned16
Fault message counter
947
R
Array [1]
Unsigned16
Currently failure code
964
R
Array [5]
Unsigned16
Inverter Unit identification
IND 0 = Manufacturer-ID
PNE001Z :
0x190
PNE001Z-1: 0x031A
IND 1 = Model number
IND 2 = Inverter CPU1 version
IND 3 = Inverter firmware release year (yyyy)
IND 4 = Inverter firmware release date (ddmm)
965
R
Array [1]
Octet String2
Profile number (PROFIdrive, V4.1)

Toshiba Tosvert VF-S15 Specifications

General

Category	Inverter
Control Method	V/f control, Sensorless vector control
Cooling Method	Forced air cooling
Model	Tosvert VF-S15
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication Options	Modbus RTU
Overload Capacity	150% for 1 minute
Braking Unit	Built-in braking transistor
Output Voltage	3-Phase, same as input voltage
Operating Temperature	-10 to +50°C (14 to 122°F)
Storage Temperature	-20 to 65°C (-4 to 149°F)
Humidity	5 to 95% RH (non-condensing)
Altitude	Up to 1000m above sea level
Input Voltage	3-Phase 200 to 240 VAC, 3-Phase 380 to 480 VAC
Weight	Varies depending on model (e.g., 0.8 kg to 16 kg)
