6.7.1. Examples of reading the PROFIdrive parameter
6.7.1.1. Example 1. Reading the PNU 922 (Telegram)
AK = 1 (Request parameter value)
SPM = 0
PNU = 922 (0x039A)
PKE
0
0
0
1
0
0
1
1
1
0
0
1
1
0
1
0
1
3
9
A
Requirement
PKW PZD
PKE IND PWE
13
9A
00
00
00
00
00
00
･･･
･･･
Response (Value: 0x0065 = Telegram101)
13
9A
00
00
00
00
00
65
･･･
･･･
6.7.1.2. Example 2. Reading the PNU 964, IND 0
AK = 6 (Request parameter value (array))
SPM = 0
PNU = 964 (0x03C4)
IND = 1 (
Model number
)
PKE
0
1
1
0
0
0
1
1
1
1
0
0
0
1
0
0
6
3
C
4
Requirement
PKW PZD
PKE IND PWE
63
C4
00
01
00
00
00
00
･･･
･･･
Response (Value: 0x00E0 = VF-S15)
43
C4
00
01
00
00
00
E0
･･･
･･･
