Toshiba Tosvert VF-S15

E6582051
- 34 -
6.1. Telegram 100: Vendor specific
The parameter access via PKW, and the transmission of two commands and monitors via cyclic data are
supported by Telegram 100.
6.2. Telegram 101: Vendor specific
The parameter access via PKW, and the transmission of six commands and monitors via cyclic data are
supported by Telegram 101.
PLC → INV
INV → PLC
PKW1
PKW1(PKE)
PKW1(PKE)
PKW2
PKW2(IND)
PKW2(IND)
PKW3
PKW3(PWE1)
PKW3(PWE1)
PKW4
PKW4(PWE2)
PKW4(PWE2)
Cyclic data 1
c001
c021
Cyclic data 2
c002
c022
INV: Inverter
PKW: Parameter ID/value
PKE: Parameter ID (1st and 2nd octet)
IND: Sub-index (3rd octet),
4th octet is reserved
PWE: Parameter value (5th until 8th octet)
PLC → INV
INV → PLC
PKW1
PKW1(PKE)
PKW1(PKE)
PKW2
PKW2(IND)
PKW2(IND)
PKW3
PKW3(PWE1)
PKW3(PWE1)
PKW4
PKW4(PWE2)
PKW4(PWE2)
Cyclic data 1
c001
c021
Cyclic data 2
c002
c022
Cyclic data 3
c003
c023
Cyclic data 4
c004
c024
Cyclic data 5
c005
c025
Cyclic data 6
c006
c026
INV: Inverter
PKW: Parameter ID/value
PKE: Parameter ID (1st and 2nd octet)
IND: Sub-index (3rd octet),
4th octet is reserved
PWE: Parameter value (5th until 8th octet)
