7. PROFIdrive acyclic parameter access
In this product, inverter parameters and PROFIdrive parameters are accessible by acyclic
communications in addition to the cyclic communication via Telegram 100 or101.
Notes
When you use acyclic parameter access, the value is written to the EEPROM.
7.1. Example1. Read the PROFIdrive parameter
7.1.1. Request Format (Read the value of PNU 964 (0x03C4) IND 0)
Field
Description
Value
Request Header (Byte 1)
Request Reference
0x01
Request Header (Byte 2)
Request ID (0x01: Request)
0x01
Request Header (Byte 3)
Axis
0x01
Request Header (Byte 4)
Number of Parameters
0x01
Parameter Address (Byte 1)
Attribute (0x10: Value)
0x10
Parameter Address (Byte 2)
Number of Elements
0x01
Parameter Address (Byte 3)
Parameter number (PNU), High byte
0x03
Parameter Address (Byte 4)
Parameter number (PNU), Low byte
0xC4
Parameter Address (Byte 5)
Sub index (IND), High byte
0x00
Parameter Address (Byte 6)
Sub index (IND), Low byte
0x00
7.1.2. Response format
Field
Description
Value
Request Header (Byte 1)
Request Reference (mirrored)
0x01
Request Header (Byte 2)
Response ID
0x01
Request Header (Byte 3)
Axis (mirrored)
0x01
Request Header (Byte 4)
Number of Parameters
0x01
Parameter Value (Byte 1)
Format
0x06
Parameter Value (Byte 2)
Number of Values
0x01
Parameter Value (Byte 3)
Values, High byte
0x01
Parameter Value (Byte 4)
Values, Low byte
0x90
