Toshiba Tosvert VF-S15 Manual

E6582051
- 19 -
4.1.2. Relation parameters for VF-AS3
Title
Communi
cation No.
Function Description
Default
setting
cmod
0003 Command mode selection
0: Terminal board
1: Operation panel, Extension panel
2: Embedded Ethernet
3: RS485 communication (connector 1)
4: RS485 communication (connector 2)
5 : Communication option
0
fmod
0004
Frequency setting mode
selection 1
0: -
1: Terminal RR
2: Terminal RX
3: Terminal II
4: Terminal AI4 (option)
5: Terminal AI5 (option)
6-9:-
10: Touch wheel 1 (power off or press OK to save)
11: Touch wheel 2 (press OK to save)
12:
sr0
13,14:-
15: Terminal Up/Down frequency
16:
Pulse train
17: High resolution pulse train (option)
18,19:-
20: Embedded Ethernet
21: RS485 communication (connector 1)
22: RS485 communication (connector 2)
23: Communication option
1
f519
0519
Setting of acceleration /
deceleration time unit
0: -
1: 0.01s unit (0 after execution)
2: 0.1s unit (1 after execution)
0
(*1)
f749
0749
Integrating wattmeter display
unit selection
0: 1.0=1kWh
1: 1.0=10kWh
2: 1.0=100kWh
3: 1.0=1000kWh
4: 1.0=10000kWh
5: 1.0=100000kWh
(*2)
f856
0856
Number of motor pole pair for
communication
1: 2 poles
2: 4 poles
3: 6 poles
4: 8 poles
5: 10 poles
6: 12 poles
7: 14 poles
8: 16 poles
2
f898
0898 Reset mode selection (*3)
0: Clear trip by request from communication
option. Reset by request except from
communication option..
1: Reset
2: Clear trip
3 to 5: -
0
f899
0899 Communication function reset
0: -
1: Reset option and inverter
-
(*1): 0.1s unit is selected as default setting.
(*2): Default setting values vary depending on the capacity.
(*3): When you reset by
f899
=1 setting, or trip is requires a reboot of inverter, the inverter is rebooted
regardless of the parameter setting.

Toshiba Tosvert VF-S15 Specifications

General

Category	Inverter
Control Method	V/f control, Sensorless vector control
Cooling Method	Forced air cooling
Model	Tosvert VF-S15
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication Options	Modbus RTU
Overload Capacity	150% for 1 minute
Braking Unit	Built-in braking transistor
Output Voltage	3-Phase, same as input voltage
Operating Temperature	-10 to +50°C (14 to 122°F)
Storage Temperature	-20 to 65°C (-4 to 149°F)
Humidity	5 to 95% RH (non-condensing)
Altitude	Up to 1000m above sea level
Input Voltage	3-Phase 200 to 240 VAC, 3-Phase 380 to 480 VAC
Weight	Varies depending on model (e.g., 0.8 kg to 16 kg)
